A4 / V2 (black/white testversion) just before the start View: Slideshow Mosaic List 1 September 3, 2023
Beware: picture doesn't show the A4 V4 "woman in the moon" (it just serves as a basic idea.).
2 3 4 5 September 3, 2023
Thrust rudders are made of graphite
6 7 8 September 3, 2023
Unfortunately, you can't see the shading in the picture
9 10 11 12 13 14 15 16 September 3, 2023
First section primed.
17 September 3, 2023
Fully primed.
18 September 3, 2023
Partial cutting out of the flap for the Stotz plug. The connection is dropped shortly before take-off.
19 September 3, 2023
The flap for the Stotz plug. The connection is dropped shortly before take-off.
20 September 3, 2023
First paintwork in white.
21 September 3, 2023
My first attempt: pouring the concrete slabs for the ground
22 September 3, 2023
My first attempt: pouring the concrete slabs for the ground
23 September 3, 2023
The cast plates.
24 September 10, 2023
Starting the base.
25 September 10, 2023
Cutting the panels.
26 September 10, 2023
The concrete slabs have been laid.
27 September 10, 2023
Preshading.
28 September 10, 2023
Painting the base
29 September 10, 2023
Test of the lineup.
30 September 10, 2023
“Fun” with masking, 4 hours later.
31 32 September 10, 2023
Scratch built, painted and weathered rails and shafts
33 September 10, 2023
Rail shafts added to the base
34 September 10, 2023
Rail shafts and rails added to the base
35 September 10, 2023
Rail shafts and rails added to the base
36 September 10, 2023
Rail shafts and rails added to the base
37 38 September 16, 2023
Reference for the line tower
39 September 16, 2023
scratch built line tower, base comes fom the kit
40 September 16, 2023
scratch built line tower
41 September 16, 2023
scratch built cables
42 September 16, 2023
scratch built cables
43 September 16, 2023
painted and weathered line tower
44 November 22, 2023
Repainted - white as base color
45 November 22, 2023
Repainted - white as base color
46 November 22, 2023
new beginning by painting the black/white pattern
47 November 22, 2023
new beginning by painting the black/white pattern
48 November 22, 2023
slight covering errors
49 November 22, 2023
Eliminate paint defects by repainting the affected white areas
50 51 November 22, 2023
Steps in the black/white pattern
52 November 22, 2023
Steps in the black/white pattern
53 November 22, 2023
Decal from the picture "Woman in the Moon" without a light background.
54 November 22, 2023
The picture (as a lucky charm) on the V2 was originally painted on an apparently grayish background.
55 November 22, 2023
For the light grey/whitish background I used decals from a whitish/greyish license plate base from another kit
56 November 22, 2023
For the light grey/whitish background I used decals from a whitish/greyish license plate base from another kit
57 November 22, 2023
finished picture of the "woman in the moon"
58 November 22, 2023
Painting in the final phase, clear coat is satisfactory this time.
59 November 22, 2023
Painting in the final phase, clear coat is satisfactory this time.
60 January 21, 2024
Panel line washing
61 January 21, 2024
Panel line washing
62 January 21, 2024
Clamping levers
63 January 21, 2024
Scratchbuilding of the clamping levers
64 January 21, 2024
Scratchbuilding of the clamping levers
65 January 21, 2024
Connection pipe
66 January 21, 2024
Scratchbuilding of the Connection pipe
67 January 21, 2024
Scratchbuilding of the connection pipe
68 January 21, 2024
Reference: Device for igniting the rocket motor
69 January 21, 2024
Scratchbuilding of the device for igniting the rocket motor
70 January 21, 2024
Scratchbuilding of the device for igniting the rocket motor
71 March 9, 2024
Reference: cables on the switch/fuse box
72 March 9, 2024
Scratchbuilding cables on the switch/fuse box
73 March 9, 2024
Scratchbuilding cables on the switch/fuse box
74 March 9, 2024
Scratchbuilding cables on the switch/fuse box
75 March 9, 2024
Scratchbuilding cables on the switch/fuse box
76 March 9, 2024
Scratchbuilding cables on the switch/fuse box
77 March 9, 2024
series of tests to replicate the ice that forms on the rocket due to the liquid oxygen tank in the lower segment
78 March 9, 2024
Replica of the ice forming on the rocket after filling with liquid oxygen
79 March 9, 2024
Replica of the ice forming on the rocket after filling with liquid oxygen
80 March 9, 2024
Positioning/attachment of the rocket with launch table to the base plate
81 March 9, 2024
Positioning/attachment of the rocket with launch table to the base plate
82 March 9, 2024
Positioning/attachment of the rocket with launch table to the base plate, drilling a countersunk hole for the screw
83 March 9, 2024
Positioning/attachment of the rocket with launch table to the base plate
84 March 9, 2024
Positioning/attachment of the rocket with launch table to the base plate
85 March 9, 2024
Glue the screw nut into the launch table of the rocket
86 87 March 9, 2024
scratch building the connecting lines
88 March 9, 2024
scratch building the connecting lines
89 March 9, 2024
scratch building the connecting lines and the smoke formation, immediately before the rocket motor is ignited, weathering of the ground
90 91 92 93 94 Comments 23 November 2024, 00:14 -
Album info My version will be the A4 "Frau im Mond", the fourth launched A4.
It was painted in a high-contrast black and white to better observe and track the movement of the missile during flight.
V4 (fourth launched A4) -"Frau im Mond" was launched on 10/03/1942. It was the first successful start of an A4. It reached a top speed of 4,824 km/h (about Mach 4.5) and reached a top altitude of 84.5 km, thus reaching the frontier of space for the first time. This was the first successful large rocket launch in human history an the first time, a man-made object reached the limits of space.
I really like the high-contrast black/white finish. It goes contrary to the usual finishes in the military sector; an appealing change.
